EcoSavers Countdown Timer AT328 User Manual

1. ఉత్పత్తి ముగిసిందిview

The EcoSavers Countdown Timer is an energy-saving device designed to automatically control the power supply to connected appliances. It features four pre-set switching times, allowing you to set a duration after which the connected device will automatically turn off (or on, depending on the application). This helps reduce energy consumption and provides convenience for various household or office electronics.

మూర్తి 1: EcoSavers Countdown Timer. The image displays the EcoSavers Countdown Timer, a white device with a green-colored socket, packaged in a green and white box. The box highlights 'Countdown Timer' and 'Save Energy' features. The device itself shows indicators for different time settings.

2. భద్రతా సూచనలు

• ఉపయోగం ముందు అన్ని సూచనలను జాగ్రత్తగా చదవండి.
• This device is for indoor use only. Do not expose to moisture or extreme temperatures.
• Do not exceed the maximum load capacity of 16A / 3680W. Overloading can cause damage to the timer and connected appliances, and may pose a fire hazard.
• Ensure the timer is securely plugged into a grounded wall socket.
• Do not disassemble or attempt to repair the timer. Refer all servicing to qualified personnel.
• Keep out of reach of children. This product includes child protection features, but supervision is always recommended.
• Unplug the timer from the wall socket before cleaning.

3. ఉత్పత్తి లక్షణాలు

• శక్తి ఆదా: Automatically switches off connected devices after a set time.
• Pre-set Times: Offers 4 fixed countdown durations (1/2 hour, 1 hour, 3 hours, 6 hours).
• పిల్లల రక్షణ: Integrated safety features to prevent accidental tampఈరింగ్.
• మన్నికైన పదార్థం: Constructed from flame-retardant PC material for enhanced safety.
• ధృవీకరించబడింది: GS certified for quality and safety standards.

4. సెటప్

1. అన్‌ప్యాక్: Carefully remove the EcoSavers Countdown Timer from its packaging.
2. తనిఖీ: పరికరంలో ఏవైనా కనిపించే నష్టం ఉందో లేదో తనిఖీ చేయండి. దెబ్బతిన్నట్లయితే ఉపయోగించవద్దు.
3. ప్లగ్ ఇన్: Insert the timer into a standard 230V / 50Hz wall socket.
4. ఉపకరణాన్ని కనెక్ట్ చేయండి: Plug the appliance you wish to control into the socket on the front of the EcoSavers Countdown Timer. Ensure the appliance is switched on if it has its own power switch.

5. ఆపరేటింగ్ సూచనలు

The EcoSavers Countdown Timer features a simple push-button operation to select the desired countdown duration.

1. పవర్ ఆన్: Once the timer is plugged into the wall and an appliance is connected, the timer is ready for use.
2. సమయాన్ని ఎంచుకోండి: Press the button on the timer repeatedly to cycle through the available countdown settings: 1/2 hour, 1 hour, 3 hours, and 6 hours.
3. సూచిక: An LED indicator next to each time setting will illuminate to show the currently selected duration.
4. కౌంట్‌డౌన్ ప్రారంభించండి: Once a time setting is selected, the countdown begins automatically. The connected appliance will remain powered during this period.
5. ఆటోమేటిక్ షట్-ఆఫ్: When the selected countdown duration expires, the timer will automatically cut power to the connected appliance.
6. Reset/Turn Off: To stop the countdown prematurely or to turn off the timer function, press the button until no LED indicator is lit. This will cut power to the connected appliance.

6. నిర్వహణ

• శుభ్రపరచడం: శుభ్రపరిచే ముందు పవర్ అవుట్‌లెట్ నుండి టైమర్‌ను డిస్‌కనెక్ట్ చేయండి. బాహ్య భాగాన్ని మృదువైన, పొడి గుడ్డతో తుడవండి. ద్రవ క్లీనర్‌లను లేదా రాపిడి పదార్థాలను ఉపయోగించవద్దు.
• నిల్వ: ఉపయోగంలో లేనప్పుడు టైమర్‌ను చల్లని, పొడి ప్రదేశంలో నిల్వ చేయండి.
• తనిఖీ: Periodically inspect the timer and its plug for any signs of wear or damage.

7. ట్రబుల్షూటింగ్

• Timer not turning on/off:
  • Ensure the timer is securely plugged into a live wall socket.
  • Verify that the connected appliance is functioning correctly when plugged directly into a wall socket.
  • Check if a countdown duration has been selected and its LED indicator is lit.
• ఉపకరణానికి విద్యుత్ సరఫరా అందడం లేదు:
  • Confirm the appliance's own power switch is in the 'ON' position.
  • Ensure the timer has not completed its countdown cycle.
  • Check if the timer is overloaded. Reduce the total wattagకనెక్ట్ చేయబడిన పరికరాల ఇ.

If problems persist, contact customer support or a qualified electrician.

8. స్పెసిఫికేషన్లు

9. వారంటీ మరియు మద్దతు

For warranty information, please refer to the terms and conditions provided by your retailer at the time of purchase. If you encounter any issues or require technical assistance, please contact the retailer where you purchased the EcoSavers Countdown Timer or visit the official EcoSavers webమద్దతు వనరుల కోసం సైట్.
