1. ఉత్పత్తి ముగిసిందిview
The Homtime C1-PRO is a versatile music alarm clock designed to enhance your daily routine. It features a Bluetooth speaker for audio playback, dual USB ports for charging devices, a personalized alarm ring function, a built-in thermometer, and a 3-level dimmable display for optimal visibility.
Figure 1: Homtime C1-PRO with icons illustrating key features such as snooze, dual USB charging, melody alarm, time/alarm knob, Bluetooth, and thermometer.
ముఖ్య లక్షణాలు:
- బ్లూటూత్ స్పీకర్: Connect wirelessly to play audio from your devices.
- డ్యూయల్ USB ఛార్జింగ్ పోర్ట్లు: Conveniently charge two devices simultaneously.
- Personalized Alarm Ring: Customize your alarm sound using a MicroSD card.
- Digital Thermometer: Displays ambient room temperature.
- 3-Level Dimmable Display: Adjust screen brightness for comfort.
- తాత్కాలికంగా ఆపివేయి ఫంక్షన్: Temporarily pause the alarm.
Figure 2: Front panel controls and display elements, including time, alarm clock indicator, snooze on/off, Bluetooth on/off, temperature, and USB charging ports.
Figure 3: Rear panel controls, including the alarm set button, rotary dial for speaker volume, time set switch, time mode switch (12HR/24HR), Bluetooth on/off switch, MicroSD card slot for alarm personalization, and alarm volume control dial.
Figure 4: Bottom panel details, showing the temperature sensor, USB charging ports, power input jack, battery compartment for 3A batteries (not included), and temperature switch (°C/°F).
2. సెటప్
2.1 పవర్ కనెక్షన్
- Connect the provided power adapter to the "Power Input Jack" located on the bottom of the unit (refer to Figure 4).
- అడాప్టర్ను ప్రామాణిక గోడ అవుట్లెట్లోకి ప్లగ్ చేయండి. డిస్ప్లే వెలుగుతుంది.
2.2 Battery Backup Installation (Optional)
The C1-PRO uses 3A batteries (not included) for backup power to retain time and alarm settings during a power outage. These batteries do not power the main functions of the clock.
- Locate the battery compartment on the bottom of the unit (refer to Figure 4).
- బ్యాటరీ కంపార్ట్మెంట్ కవర్ తెరవండి.
- Insert the required 3A batteries, ensuring correct polarity (+/-).
- బ్యాటరీ కంపార్ట్మెంట్ కవర్ను సురక్షితంగా మూసివేయండి.
2.3 ప్రారంభ సెట్టింగ్లు
- Time Format (12HR/24HR): Locate the "Time Mode Switch (12HR/24HR)" on the rear panel (refer to Figure 3). Slide the switch to your preferred time format.
- ఉష్ణోగ్రత యూనిట్ (°C/°F): Locate the "Temperature Switch (°C/°F)" on the bottom panel (refer to Figure 4). Slide the switch to select Celsius or Fahrenheit.
3. ఆపరేటింగ్ సూచనలు
3.1 సమయాన్ని సెట్ చేయడం
- Locate the "Time Set Switch" on the rear panel (refer to Figure 3).
- Slide the switch to the "SET" position. The hour digits will begin to flash.
- Rotate the "Knob for time and alarm-setting" (top center, refer to Figure 1) to adjust the hour.
- Press the knob once to switch to minute adjustment. The minute digits will flash.
- నిమిషాలను సర్దుబాటు చేయడానికి నాబ్ని తిప్పండి.
- Press the knob again or slide the "Time Set Switch" back to "LOCK" to confirm and exit time setting mode.
3.2 అలారం సెట్ చేస్తోంది
- Press the "Alarm Set Button" on the rear panel (refer to Figure 3). The alarm time will appear on the display, and the hour digits will flash.
- Rotate the "Knob for time and alarm-setting" to adjust the alarm hour.
- Press the knob once to switch to minute adjustment. The minute digits will flash.
- Rotate the knob to adjust the alarm minutes.
- Press the knob again to confirm the alarm time. The alarm icon will appear on the display, indicating the alarm is active.
- To deactivate the alarm, press the "Alarm Set Button" again. The alarm icon will disappear.
3.3 Personalized Alarm Ring (MicroSD Card)
You can use your own audio files as an alarm sound by inserting a MicroSD card.
- Insert a MicroSD card containing your desired MP3 audio files into the "MicroSD Card Slot for Alarm Personalization" on the rear panel (refer to Figure 3).
- When setting the alarm, after confirming the time, the clock will automatically use the first compatible audio file on the MicroSD card as the alarm sound.
- ఆడియోను నిర్ధారించుకోండి fileలు మద్దతు ఉన్న ఫార్మాట్లో ఉన్నాయి (ఉదా., MP3).
3.4 స్నూజ్ ఫంక్షన్
When the alarm sounds, press the large "Snooze/Dimmer Button" on the top of the unit (the large silver button, refer to Figure 1). The alarm will pause for approximately 9 minutes and then sound again. This can typically be repeated multiple times.
3.5 బ్లూటూత్ స్పీకర్ ఆపరేషన్
- Locate the "Bluetooth ON/OFF Switch" on the rear panel (refer to Figure 3). Slide it to the "ON" position.
- The Bluetooth icon on the display will flash, indicating it is in pairing mode.
- మీ మొబైల్ పరికరంలో, బ్లూటూత్ని ప్రారంభించండి మరియు అందుబాటులో ఉన్న పరికరాల కోసం శోధించండి.
- Select "Homtime C1-PRO" from the list to pair. Once paired, the Bluetooth icon on the clock's display will stop flashing and remain solid.
- You can now play audio from your device through the C1-PRO speaker.
- Adjust the speaker volume using the "Rotary Dial for Speaker Volume Control" on the rear panel (refer to Figure 3).
- To disconnect, turn off Bluetooth on your device or slide the "Bluetooth ON/OFF Switch" on the clock to "OFF".
3.6 USB ఛార్జింగ్
The C1-PRO features two USB charging ports on the front of the unit (refer to Figure 2). Connect your USB charging cables to these ports to charge compatible devices such as smartphones or tablets.
- Ensure the clock is connected to power for the USB charging function to operate.
- The charging output is standard for most mobile devices.
3.7 ప్రదర్శన ప్రకాశం సర్దుబాటు
The display has 3 levels of brightness. To adjust, press the "Snooze/Dimmer Button" (large silver button on top, refer to Figure 1) when the alarm is not sounding. Each press will cycle through the brightness levels.
3.8 Alarm Volume Control
Adjust the alarm volume using the "Alarm Volume Control Dial" located on the rear panel (refer to Figure 3).
4. నిర్వహణ
- శుభ్రపరచడం: Use a soft, dry cloth to clean the surface of the clock. Do not use liquid cleaners or abrasive materials.
- నిల్వ: If storing the device for an extended period, disconnect it from power and remove the backup batteries. Store in a cool, dry place.
- బ్యాటరీ భర్తీ: Replace backup batteries annually or when the clock fails to retain settings during a power interruption.
5. ట్రబుల్షూటింగ్
| సమస్య | సాధ్యమైన కారణం | పరిష్కారం |
|---|---|---|
| గడియార ప్రదర్శన ఆపివేయబడింది లేదా పనిచేయడం లేదు. | విద్యుత్ కనెక్షన్ లేదు. | Ensure the power adapter is securely plugged into the clock and a working wall outlet. |
| అలారం మోగడం లేదు. | Alarm is not activated; volume is too low; MicroSD card issue. | Verify the alarm icon is displayed. Adjust the alarm volume dial. If using MicroSD, ensure the card is inserted correctly and contains compatible audio files. |
| బ్లూటూత్ జత చేయడం లేదు. | Bluetooth switch off; device too far; already paired with another device. | Ensure the Bluetooth switch on the clock is ON and flashing. Move your device closer. Disconnect from other Bluetooth devices. |
| USB ఛార్జింగ్ పనిచేయడం లేదు. | Clock not powered; faulty cable/device. | Ensure the clock is connected to its power adapter. Try a different USB cable or device to rule out external issues. |
| పవర్ OU తర్వాత సమయం/సెట్టింగ్లు పోయాయిtage. | Backup batteries not installed or depleted. | Install fresh 3A backup batteries (refer to Section 2.2). |
6. స్పెసిఫికేషన్లు
| ఫీచర్ | వివరాలు |
|---|---|
| బ్రాండ్ | హోమ్టైమ్ |
| మోడల్ | C1-PRO |
| రంగు | నలుపు |
| ప్రదర్శన రకం | డిజిటల్ |
| ప్రత్యేక లక్షణాలు | Alarm, USB Charging, Bluetooth, Thermometer, Dimmable Display |
| శక్తి మూలం | Electrical (with battery backup) |
| ఫ్రేమ్ మెటీరియల్ | ప్లాస్టిక్ |
| కనెక్టివిటీ టెక్నాలజీ | బ్లూటూత్ |
| ఉత్పత్తి కొలతలు (LxWxH) | 10.92 x 10.92 x 6.35 సెం.మీ (సుమారుగా 4.3 x 4.3 x 2.5 అంగుళాలు) |
| వస్తువు బరువు | 259 గ్రా (సుమారు 0.57 పౌండ్లు) |
| Battery Type (Backup) | 3A (చేర్చబడలేదు) |
7. వారంటీ మరియు మద్దతు
For warranty information and customer support, please refer to the documentation included with your purchase or visit the official Homtime webసైట్. ఏవైనా వారంటీ క్లెయిమ్ల కోసం మీ కొనుగోలు రుజువును ఉంచుకోండి.
