పరిచయం
This manual provides essential information for the safe and efficient operation, installation, and maintenance of your Gree Multi21+ Tri-Zone Floor Console Mini Split Air Conditioner Heat Pump system. Please read this manual thoroughly before using the product and retain it for future reference.
ముఖ్యమైన భద్రతా సమాచారం
యూనిట్కు గాయం లేదా నష్టం జరగకుండా ఉండటానికి ఎల్లప్పుడూ క్రింది భద్రతా జాగ్రత్తలను పాటించండి.
- వృత్తిపరమైన సంస్థాపన: Installation must be performed by a state-licensed HVAC contractor. Improper installation can lead to electric shock, fire, water leakage, or other hazards.
- విద్యుత్ సరఫరా: Ensure the unit is connected to a dedicated power circuit with the correct voltage (208/230V). Do not use extension cords.
- రిఫ్రిజెరాంట్: This system uses R-410A refrigerant. Only qualified personnel should handle refrigerant.
- విద్యుత్ భద్రత: Do not operate the unit with wet hands. Disconnect power before cleaning or servicing.
- పిల్లలు మరియు పెంపుడు జంతువులు: ముఖ్యంగా ఆపరేషన్ మరియు నిర్వహణ సమయంలో పిల్లలు మరియు పెంపుడు జంతువులను యూనిట్ నుండి దూరంగా ఉంచండి.
- వెంటిలేషన్: ఓవర్ హీటింగ్ నివారించడానికి అవుట్డోర్ యూనిట్ చుట్టూ సరైన వెంటిలేషన్ ఉండేలా చూసుకోండి.
ఉత్పత్తి ముగిసిందిview
The Gree Multi21+ Tri-Zone system consists of one outdoor condenser unit and three indoor floor console units, designed to provide efficient heating and cooling for multiple zones.

This image displays the complete Gree Multi21+ Tri-Zone Mini Split system, featuring one outdoor condenser unit and three indoor floor console units, along with their respective remote controls. The indoor units are white and designed for floor-level installation.
Indoor Floor Console Unit
The indoor floor console units are designed for discreet placement near the floor, offering quiet and efficient climate control.

ఒక ఫ్రంట్ view of the Gree Multi21+ Floor Console indoor unit. This white unit features a sleek design with air vents at the top and bottom, and the Gree logo prominently displayed.

ఒక వైపు view of the Gree Multi21+ Floor Console indoor unit, showing its depth and design. A QR code is visible on the side panel, likely for quick access to product information or support videos.
అవుట్డోర్ కండెన్సర్ యూనిట్
The outdoor unit houses the compressor and other components responsible for the system's heating and cooling capabilities.

The Gree Multi21+ outdoor condenser unit, featuring a protective grille over the fan and the Gree logo. This unit is designed to be installed outside the building.
సెటప్ మరియు ఇన్స్టాలేషన్
The installation of the Gree Multi21+ Tri-Zone Mini Split system is complex and requires specialized knowledge and tools. It is mandatory that installation be performed by a state-licensed HVAC contractor to ensure proper function, safety, and warranty validity.
కీలక సంస్థాపన పరిగణనలు:
- Line Sets: Three 1/4" x 3/8" line sets are required for connecting the indoor units to the outdoor unit. These are not included with the system.
- విద్యుత్ వైరింగ్: Proper electrical wiring to a 208/230V power source is critical.
- పారుదల: Ensure proper condensate drainage for each indoor unit.
- మౌంటు: Indoor units can be mounted as low as six inches above the floor.
- శీతలకరణి ఛార్జింగ్: The system uses R-410A refrigerant, which must be handled by certified technicians.
ఆపరేటింగ్ సూచనలు
Your Gree Multi21+ system is controlled via a remote control for each indoor unit. The G10 inverter technology ensures quiet, energy-efficient operation and stable room temperatures.

An indoor floor console unit with its accompanying remote control. The remote allows users to adjust settings such as temperature, mode, and fan speed.
ప్రాథమిక ఆపరేషన్:
- పవర్ ఆన్/ఆఫ్: యూనిట్ను ఆన్ లేదా ఆఫ్ చేయడానికి రిమోట్ కంట్రోల్లోని పవర్ బటన్ను నొక్కండి.
- మోడ్ ఎంపిక: Use the "Mode" button to cycle through operating modes: Cool, Heat, Fan, Dry, Auto.
- ఉష్ణోగ్రత సర్దుబాటు: మీకు కావలసిన ఉష్ణోగ్రతను సెట్ చేయడానికి పైకి/క్రిందికి బాణాలను ఉపయోగించండి.
- ఫ్యాన్ వేగం: Adjust the fan speed (Low, Medium, High, Auto) using the "Fan" button.
- స్వింగ్ ఫంక్షన్: Activate the swing function for automatic louver movement to distribute air evenly.
Refer to the specific remote control manual for detailed instructions on advanced features such as timer settings, sleep mode, and special functions.
నిర్వహణ
Regular maintenance ensures optimal performance and longevity of your Gree Multi21+ system. Always disconnect power to the unit before performing any maintenance.
ఫిల్టర్ క్లీనింగ్:
- The indoor floor console units feature front panel access to the air filter for ease of cleaning.
- గాలి నాణ్యత మరియు వాడకం ఆధారంగా ప్రతి రెండు వారాలకు ఒకసారి లేదా అంతకంటే ఎక్కువసార్లు ఎయిర్ ఫిల్టర్లను శుభ్రం చేయండి.
- To clean, open the front panel, remove the filters, and wash them with lukewarm water and mild detergent. Rinse thoroughly and allow them to dry completely before reinserting.
వృత్తిపరమైన నిర్వహణ:
It is recommended to have a licensed HVAC technician perform annual inspections and maintenance, including checking refrigerant levels, cleaning coils, and inspecting electrical connections.
ట్రబుల్షూటింగ్
కస్టమర్ మద్దతును సంప్రదించే ముందు, తిరిగిview కింది సాధారణ సమస్యలు మరియు పరిష్కారాలు:
| సమస్య | సాధ్యమైన కారణం | పరిష్కారం |
|---|---|---|
| యూనిట్ ఆన్ చేయబడలేదు | పవర్ లేదు, రిమోట్ కంట్రోల్ బ్యాటరీలు తక్కువగా ఉన్నాయి, సర్క్యూట్ బ్రేకర్ ట్రిప్ అయింది. | విద్యుత్ సరఫరాను తనిఖీ చేయండి, రిమోట్ బ్యాటరీలను మార్చండి, సర్క్యూట్ బ్రేకర్ను రీసెట్ చేయండి. |
| తగినంత శీతలీకరణ/వేడి లేకపోవడం | మురికి ఎయిర్ ఫిల్టర్, బ్లాక్ చేయబడిన అవుట్డోర్ యూనిట్, తప్పు మోడ్ సెట్టింగ్, తక్కువ రిఫ్రిజెరాంట్. | Clean air filter, clear obstructions from outdoor unit, verify mode, contact technician for refrigerant check. |
| అసాధారణ శబ్దం | విడి భాగాలు, ఫ్యాన్ అవరోధం, రిఫ్రిజెరాంట్ ప్రవాహ శబ్దం (సాధారణం). | Inspect for loose parts, remove obstructions. If noise persists or is abnormal, contact technician. |
| ఇండోర్ యూనిట్ నుండి నీటి లీకేజీ | మూసుకుపోయిన డ్రెయిన్ గొట్టం, సరికాని ఇన్స్టాలేషన్. | Check and clear drain hose. If issue persists, contact a licensed HVAC contractor. |
స్పెసిఫికేషన్లు
Key technical specifications for the Gree Multi21+ Tri-Zone Floor Console Mini Split Air Conditioner Heat Pump system, model MULTI24CCONS301.
- బ్రాండ్: GREE
- మోడల్ సంఖ్య: MULTI24CCONS301
- శీతలీకరణ శక్తి: 24,000 బ్రిటిష్ థర్మల్ యూనిట్లు (BTU)
- సామర్థ్యం: 2 టన్నులు
- సీజనల్ ఎనర్జీ ఎఫిషియన్సీ రేషియో (SEER): 21
- వాల్యూమ్tage: 230 వోల్ట్లు
- ధ్వని స్థాయి: 56 Decibels (Outdoor Unit)
- రిఫ్రిజెరాంట్: R-410a
- నియంత్రణ పద్ధతి: రిమోట్
- ప్రత్యేక ఫీచర్: Fast Cooling, G10 Inverter Technology
యూనిట్ కొలతలు (సుమారుగా)

This image displays a table detailing the approximate dimensions (Width x Height x Depth) for various BTU capacities of Gree Multi-Console indoor and outdoor units. For the 24,000 BTU outdoor unit, the dimensions are 38" x 31.1" x 17.3".
For specific dimensions of the 24,000 BTU outdoor unit, refer to the table above or the product's technical documentation. Indoor unit dimensions for 9,000, 12,000, and 18,000 BTU are listed as 27.6" x 23.6" x 8.5".
వారంటీ మరియు మద్దతు
Gree provides a manufacturer's warranty for this product:
- విడిభాగాల వారంటీ: 5 సంవత్సరాలు
- కంప్రెసర్ వారంటీ: 7 సంవత్సరాలు
ముఖ్యమైన: To be eligible for warranty coverage, installation must be performed by a state-licensed HVAC contractor.
For technical support, warranty claims, or service inquiries, please contact your installing HVAC contractor or refer to the official Gree website for authorized service providers.

This image displays various certifications and features of Gree products, including a "5 Year Limited Warranty" icon, "Non Ozone-Depleting Refrigerant R410A", "Heating & Cooling" icon, ETL Listed, G10 Inverter Technology, AHRI Certified, and Energy Star (except 42k model) logos.
