Green Cell UPS 600VA (360W) Line-Interactive AVR User Manual

1. పరిచయం

The Green Cell UPS 600VA (360W) Line-Interactive AVR is an Uninterruptible Power Supply designed to provide reliable power backup and surge protection for your electronic devices. This device ensures that your connected equipment, such as computers, routers, and other sensitive electronics, remains operational during power outages and is protected from voltage fluctuations. This manual provides essential information for the safe and efficient use of your UPS.

2. భద్రతా సూచనలు

• Read all instructions carefully before operating the UPS.
• UPS తెరవవద్దు casing. లోపల వినియోగదారు-సేవ చేయగల భాగాలు లేవు. సర్వీసింగ్ గురించి అర్హత కలిగిన సేవా సిబ్బందికి తెలియజేయండి.
• Do not expose the UPS to rain, moisture, or direct sunlight. Operate in a well-ventilated area.
• UPS గ్రౌండెడ్ పవర్ అవుట్‌లెట్‌కి కనెక్ట్ చేయబడిందని నిర్ధారించుకోండి.
• Do not connect appliances that draw high current, such as laser printers, heaters, or vacuum cleaners, to the UPS outlets.
• The internal battery is a VRLA lead-acid type. Do not dispose of batteries in a fire, as they may explode. Follow local regulations for battery disposal.
• In case of emergency, press the power button to turn off the UPS and disconnect it from the main power supply.

3. ప్యాకేజీ విషయాలు

ప్యాకేజీలో అన్ని అంశాలు ఉన్నాయని నిర్ధారించుకోండి:

• Green Cell UPS 600VA (360W)
• Power Cable (C13 type)
• USB కమ్యూనికేషన్ కేబుల్
• వినియోగదారు మాన్యువల్

4. ఉత్పత్తి ముగిసిందిview

4.1 ముందు మరియు పై ప్యానెల్

చిత్ర వివరణ: ఒక టాప్-డౌన్ view of the Green Cell UPS. The front features a green LCD display and a power button. The top panel includes multiple Schuko outlets for connecting devices and USB ports for charging or data communication.

4.2 వెనుక ప్యానెల్

చిత్ర వివరణ: The rear panel of the Green Cell UPS. It shows the main power input port, additional Schuko outlets, and RJ45 ports for network/phone line surge protection.

4.3 ఎల్‌సిడి డిస్ప్లే

The LCD display provides real-time information about the UPS status, including input/output voltage, battery charge level, load percentage, and operational mode. This allows for quick monitoring of the power supply conditions.

5. సెటప్

5.1 ప్రారంభ ఛార్జింగ్

Before initial use, connect the UPS to a wall outlet and allow it to charge for at least 8 hours. This ensures the internal battery is fully charged and ready to provide optimal backup power. The UPS will charge whether it is turned on or off.

5.2 కనెక్ట్ చేసే పరికరాలు

Plug your electronic devices into the Schuko outlets on the UPS. Ensure that the total power consumption of all connected devices does not exceed the UPS's maximum capacity of 360W (600VA). Use the USB ports for charging compatible devices or for connecting the UPS to a computer for monitoring.

చిత్ర వివరణ: The Green Cell UPS positioned on a desk, actively providing power to several electronic devices plugged into its outlets. The LCD screen is illuminated, indicating operational status.

5.3 సాఫ్ట్‌వేర్ ఇన్‌స్టాలేషన్

For advanced monitoring and management features, install the Green Cell UPS software on your computer. Connect the UPS to your computer using the provided USB cable. The software allows you to:

• Monitor UPS status and parameters in real-time.
• Receive notifications for power events.
• Schedule automatic shutdowns or startups.
• Analyze power usage graphs.

చిత్ర వివరణ: A computer screen displaying the Green Cell UPS management software dashboard. It shows various parameters like input voltagఇ, ఫ్రీక్వెన్సీ, అవుట్‌పుట్ వాల్యూమ్tagఇ, లోడ్ శాతంtage, and battery charge level, providing a comprehensive overview of the UPS's operational status.

చిత్ర వివరణ: A screenshot of the Green Cell UPS software's 'Scheduler' interface. This feature enables users to configure automated actions, such as turning off the PC, based on various power events like no mains power, low battery, or UPS temperature exceeding limits.

6. ఆపరేటింగ్ సూచనలు

6.1 పవర్ ఆన్/ఆఫ్

To turn on the UPS, press and hold the power button for a few seconds until the LCD display illuminates. To turn off the UPS, press and hold the power button again until the display turns off.

6.2 Understanding LCD Display

The LCD display cycles through various information screens. Common indicators include:

• ఇన్పుట్ వాల్యూమ్tage: వాల్యూమ్tage received from the wall outlet.
• అవుట్పుట్ వాల్యూమ్tage: వాల్యూమ్tage supplied by the UPS to connected devices.
• బ్యాటరీ స్థాయి: The current charge status of the internal battery.
• లోడ్ పర్సన్tage: శాతంtage of the UPS's capacity currently being used by connected devices.
• ఆపరేటింగ్ మోడ్: Indicates if the UPS is operating on utility power or battery power.

6.3 Using Software for Monitoring

The dedicated software provides a detailed view of the UPS's performance and allows for configuration of various settings. Regularly check the software for battery health and system alerts.

చిత్ర వివరణ: A screenshot from the Green Cell UPS software, specifically the 'Device Parameters' section. It displays critical information such as input voltagఇ, అవుట్పుట్ వాల్యూమ్tage, battery charge level (78%), battery voltage (24.5V), and battery status ('correct').

7. నిర్వహణ

7.1 బ్యాటరీ భర్తీ

The UPS uses a 12V/7Ah VRLA lead-acid battery. The lifespan of the battery is typically 2-3 years, depending on usage and environmental conditions. If the UPS consistently provides short backup times or indicates a battery fault, the battery may need replacement. Contact Green Cell support for guidance on battery replacement.

7.2 శుభ్రపరచడం

Regularly clean the exterior of the UPS with a soft, dry cloth. Do not use liquid cleaners or solvents. Ensure ventilation openings are free from dust and debris to prevent overheating.

7.3 నిల్వ

If storing the UPS for an extended period, ensure the battery is fully charged. Store in a cool, dry place. Recharge the battery every 3-6 months to prevent deep discharge and prolong battery life.

8. ట్రబుల్షూటింగ్

9. స్పెసిఫికేషన్లు

10. వారంటీ మరియు మద్దతు

Green Cell products are covered by a manufacturer's warranty. For specific warranty terms and conditions, please refer to the warranty card included with your product or visit the official Green Cell website. For technical support, troubleshooting assistance, or inquiries regarding parts and service, please contact Green Cell customer service through their official channels.
