Retro-Bit Sega Genesis 2.4 GHz Wireless Controller Instruction Manual

పరిచయం

This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your Retro-Bit Sega Genesis 2.4 GHz Wireless Controller. This controller is designed for compatibility with Sega Genesis, Sega Genesis Mini, PC, Mac, PlayStation 3, and Nintendo Switch systems, offering a versatile gaming experience.

Image: The Retro-Bit Sega Genesis 2.4 GHz Wireless Controller, its retail packaging, and the two included wireless receivers (one for Sega Genesis port, one USB).

సెటప్

ప్యాకేజీ విషయాలు

ప్యాకేజీలో అన్ని అంశాలు ఉన్నాయని నిర్ధారించుకోండి:

• Retro-Bit Sega Genesis 2.4 GHz Wireless Controller
• Sega Genesis Port Receiver
• USB Port Receiver
• 3.3 అడుగుల ఛార్జింగ్ కేబుల్
• నిల్వ కేసు

Image: The Retro-Bit controller, both receivers, and the charging cable neatly organized within the included storage case.

కంట్రోలర్‌ను ఛార్జ్ చేస్తోంది

The controller features a built-in 550 mAh rechargeable battery. Before initial use, fully charge the controller using the provided 3.3ft charging cable. Connect the micro-USB end of the cable to the controller's charging port and the USB-A end to a compatible USB power source (e.g., computer USB port, USB wall adapter).

Image: The bottom edge of the controller, highlighting the micro-USB charging port and the red LED indicator light, which illuminates during charging.

పరికరాలకు కనెక్ట్ చేస్తోంది

The controller utilizes 2.4 GHz wireless technology for connection. Select the appropriate receiver for your system.

Sega Genesis / Genesis Mini

1. Insert the Sega Genesis Port Receiver into a controller port on your Sega Genesis or Sega Genesis Mini console.

2. Power on your console.

3. Press the START button on the wireless controller to power it on. The controller will automatically attempt to pair with the receiver. A solid LED on both the controller and receiver indicates a successful connection.

Image: The Sega Genesis Port Receiver, a black dongle designed to plug directly into a Sega Genesis controller port.

PC / Mac / Nintendo Switch / PS3

1. Insert the USB Port Receiver into an available USB port on your PC, Mac, Nintendo Switch dock, or PlayStation 3 console.

2. మీ పరికరాన్ని ఆన్ చేయండి.

3. Press the START button on the wireless controller to power it on. The controller will automatically attempt to pair with the receiver. A solid LED on both the controller and receiver indicates a successful connection.

Image: The USB Port Receiver, a black USB dongle compatible with various modern systems.

Image: A compatibility chart illustrating which systems are supported by the 2.4 GHz wireless controller, including Mac, PC, Nintendo Switch, PS3, and Sega Genesis Mini.

ఆపరేటింగ్ సూచనలు

బటన్ లేఅవుట్

The controller features an 8-button arcade pad layout, including a D-pad, START, SELECT/HOME, and six face buttons (A, B, C, X, Y, Z), along with two shoulder buttons (L, R).

చిత్రం: స్పష్టమైన view of the controller's face, detailing the directional pad, START button, SELECT/HOME button, and the six action buttons (A, B, C, X, Y, Z).

పవర్ ఆన్/ఆఫ్

• పవర్ ఆన్ చేయడానికి: నొక్కండి START button. The LED indicator will light up.
• పవర్ ఆఫ్ చేయడానికి: నొక్కి పట్టుకోండి START LED సూచిక ఆఫ్ అయ్యే వరకు దాదాపు 3 సెకన్ల పాటు బటన్‌ను నొక్కి ఉంచండి.

స్లీప్ మోడ్

The controller is equipped with an automatic sleep mode feature. If there is no activity for 5 minutes, the controller will enter sleep mode to conserve battery life. To wake the controller, press any button.

Gaming Range

The 2.4 GHz wireless connection provides a gaming range of up to 30 feet (approximately 9 meters) from the receiver. Optimal performance is achieved within this range without significant obstructions.

నిర్వహణ

క్లీనింగ్

To clean the controller, use a soft, dry cloth. For stubborn dirt, a slightly damp cloth can be used, followed by immediate drying. Avoid using harsh chemicals, abrasive cleaners, or excessive moisture, as these can damage the controller's finish and internal components.

బ్యాటరీ సంరక్షణ

To prolong the life of the internal lithium-ion battery:

• బ్యాటరీని తరచుగా పూర్తిగా డిశ్చార్జ్ చేయడాన్ని నివారించండి.
• ఎక్కువ కాలం ఉపయోగంలో లేనప్పుడు కంట్రోలర్‌ను చల్లని, పొడి ప్రదేశంలో నిల్వ చేయండి.
• Charge the controller periodically if stored for a long time to prevent deep discharge.

ట్రబుల్షూటింగ్

• కంట్రోలర్ కనెక్ట్ కావడం లేదు:
  Ensure the correct receiver is plugged into the device. Verify the controller is charged. Try pressing the START button to initiate pairing. If issues persist, try unplugging and re-plugging the receiver, then restarting the controller.
• Input lag or dropped connection:
  Ensure the controller is within the 30-foot operating range of the receiver. Minimize physical obstructions between the controller and receiver. Avoid strong electromagnetic interference from other wireless devices.
• కంట్రోలర్ ఛార్జ్ కావడం లేదు:
  Check that the charging cable is securely connected to both the controller and the power source. Try a different USB port or power adapter. Ensure the charging port on the controller is free of debris.
• స్పందించని బటన్లు:
  Power cycle the controller and reconnect it. If specific buttons are consistently unresponsive, contact customer support.

స్పెసిఫికేషన్లు

వారంటీ మరియు మద్దతు

For information regarding product warranty, technical support, or service, please refer to the official Retro-Bit website or contact their customer service department. Details are typically available on the manufacturer's packaging or official product pages.
