ATOTO S8 Pro Double DIN Android Autoradio User Manual

1. పరిచయం

This manual provides detailed instructions for the ATOTO S8 Pro Double DIN Android Autoradio, designed to enhance your in-car entertainment and connectivity experience. Please read this manual thoroughly before installation and operation to ensure proper use and optimal performance of your device.

2. ఉత్పత్తి ముగిసిందిview

The ATOTO S8 Pro (Gen 2) is an advanced Android car stereo featuring a 10.1-inch QLED display. It integrates a powerful UNISOC 7862 ARM Cortex Octa-Core CPU and runs on ATOTO AICE UI 11.0, based on Android Q (10.0). This unit offers comprehensive connectivity options, including wireless CarPlay and Android Auto, dual Bluetooth, and an integrated 4G cellular modem.

Image: The ATOTO S8 Pro head unit with its 10.1-inch QLED display, showing the main interface with various application icons.

3 కీ ఫీచర్లు

• 10.1-inch QLED Display: Full HD 1280x720 capacitive touchscreen with 600cd/m2 brightness, offering a 178° full viewing కోణం మరియు అధిక కాంట్రాస్ట్.
• వైర్‌లెస్ కార్‌ప్లే & ఆండ్రాయిడ్ ఆటో: Seamless smartphone integration for navigation, music, calls, and messages.
• డ్యూయల్ బ్లూటూత్: BT1 (Qualcomm Bluetooth 5.0) with aptX and aptX HD codec for high-quality audio streaming and hands-free calling. BT2 (Bluetooth 4.1) for internet tethering and connecting other BT devices.
• Integrated 4G Cellular Modem: Supports major European and Asian frequency bands for direct internet access (SIM card not included).
• అధునాతన ఆడియో ప్రాసెసింగ్: Built-in Digital Signal Processor (DSP) with 32-band EQ, 9 preset EQ modes, signal delay adjustment, bass boost, and bass filter. BTL Max 4*49W / RMS 4*29W ampజీవితకాలం.
• DriveChat AI Assistant: Voice control for managing the car radio, answering calls, and controlling music, with customizable wake words.
• Virtual Surround-View (VSV) & Live Rear-View (LRV): Requires ATOTO AC-HD03LR camera (not included) for enhanced parking and driving visibility.
• Speed Compensated Volume Control (SCVC): Automatically adjusts volume based on vehicle speed to counteract road noise.
• Multiple Internet Access Options: WiFi, Bluetooth tethering, USB tethering, and integrated 4G modem.
• Quick System Boot & Split Screen Display: Efficient operation and multitasking capabilities.

Image: The DriveChat GenAI Assistant interface on the ATOTO S8 Pro screen, highlighting AI-powered voice control and various chatbot functionalities.

4. ప్యాకేజీ విషయాలు

క్రింద జాబితా చేయబడిన అన్ని అంశాలు మీ ఉత్పత్తి ప్యాకేజీలో చేర్చబడ్డాయని ధృవీకరించండి. ఏవైనా అంశాలు తప్పిపోయినా లేదా దెబ్బతిన్నా, దయచేసి కస్టమర్ మద్దతును సంప్రదించండి.

• ATOTO S8 Pro Head Unit (10.1-inch display)
• 20-పిన్ వైర్ జీను
• RCA కేబుల్ సెట్
• 4-in-1 Antenna (WiFi/GPS/Cellular Network)
• 2-in-1 USB Cable (External Storage & Phone Link)
• బాహ్య మైక్రోఫోన్
• DIN Pocket
• DIN Sleeve 1
• DIN Sleeve 2
• మౌంటు బ్రాకెట్లు
• మౌంటు స్క్రూలు
• ఆన్‌లైన్ వనరుల త్వరిత గైడ్
• Product Online Support Card

Image: A visual representation of all components included in the ATOTO S8 Pro package, such as the head unit, wiring harnesses, antennas, USB cables, microphone, mounting hardware, and documentation.

5. సెటప్ మరియు ఇన్‌స్టాలేషన్

5.1. ఇన్‌స్టాలేషన్ మార్గదర్శకాలు

The ATOTO S8 Pro uses a DAH10D mounting style, which is a double DIN adaptive head unit for a 10.1-inch floating screen. The 10.1-inch screen (252x155 mm) extends from the double DIN base (178x100 mm), allowing for height and viewing angle adjustments. Ensure that the screen does not obstruct vehicle controls or air vents after installation. Professional installation is recommended.

5.2. వైరింగ్ రేఖాచిత్రం

Refer to the following diagram for correct wiring connections. Incorrect wiring can damage the unit or vehicle electrical system.

Image: Detailed wiring diagram for the ATOTO S8 Pro, showing connections for power, speakers, RCA outputs, USB, microphone, GPS/4G antenna, and steering wheel controls.

5.3. Display Module Installation

When installing the display module, ensure all screw holes are properly aligned and tightened. Failure to do so may result in display issues such as scratches, frozen screens, or blurry images.

6. ఆపరేటింగ్ సూచనలు

6.1. System Navigation

The unit runs on ATOTO AICE UI 11.0. Navigate through applications and settings using the 10.1-inch capacitive touchscreen. The system supports multi-finger gestures for quick access to multitasking menus, EQ modes, and brightness adjustments.

Image: Illustration of two-finger and three-finger touch gestures for quick access to various functions on the ATOTO S8 Pro screen.

6.2 కనెక్టివిటీ

• ఇంటర్నెట్ సదుపాయం: Connect to the internet via built-in WiFi, Bluetooth tethering from your phone, USB tethering, or by inserting a 4G SIM card into the integrated cellular modem.
• బ్లూటూత్: BT1 (Bluetooth 5.0) handles phone calls and high-quality audio streaming with aptX HD. BT2 (Bluetooth 4.1) is for internet tethering and connecting other Bluetooth devices like OBDII scanners.
• Phone Integration (CarPlay/Android Auto): Connect your iPhone or Android smartphone wirelessly or via USB for seamless access to navigation, music, messaging, and calls directly from the S8 Pro display.
• GPS నావిగేషన్: The integrated GPS module with an external antenna uses Google Maps as the default navigation application. Offline map data can be downloaded for use without an internet connection.

Image: Diagram illustrating the multiple network options (4G, WiFi, Bluetooth, USB tethering) and seamless IoT hub capabilities of the ATOTO S8 Pro, showing connections to various Bluetooth-enabled devices.

6.3. ఆడియో సెట్టింగ్‌లు

Utilize the built-in DSP to fine-tune your audio experience. Adjust the 32-band equalizer, select from 9 preset EQ modes, set signal delays, and control bass boost and filter settings. The unit provides 4-channel RCA audio output and a separate sub-woofer output for connecting external ampజీవితకారులు.

Image: Visual representation of the ATOTO S8 Pro's high-fidelity audio features, including Speed Compensated Volume Control (SCVC), Digital Signal Processor (DSP), 36-band EQ, and 4V RCA outputs for a sophisticated audio system.

6.4. కెమెరా ఫీచర్లు

When connected to an ATOTO AC-HD03LR camera (sold separately), the S8 Pro supports HD Virtual Surround-View (VSV) మరియు లైవ్ రియర్-View (LRV). VSV provides a virtual panoramic view for parking, while LRV allows you to see the rear view while driving forward, reducing blind spots caused by vehicle structures or passengers.

Image: Display showing the dual live camera view feature of the ATOTO S8 Pro, including front and rear recording camera feeds, with benefits like glare suppression, wide dynamic range, and crisp license plate views.

6.5 ఇతర విధులు

• Digital Photo Frame: Display memorable photos on the large HD screen.
• USB నెట్‌వర్క్ టెథరింగ్: Share your phone's internet data with the S8 unit via a USB connection.

7. నిర్వహణ

To ensure the longevity and optimal performance of your ATOTO S8 Pro, follow these maintenance guidelines:

• శుభ్రపరచడం: స్క్రీన్ మరియు యూనిట్ శుభ్రం చేయడానికి మృదువైన, పొడి వస్త్రాన్ని ఉపయోగించండి. రాపిడి క్లీనర్లు లేదా ద్రావకాలను నివారించండి.
• సాఫ్ట్‌వేర్ అప్‌డేట్‌లు: Regularly check for and install system firmware updates available via OTA (Over-The-Air) through the FindApps application. Updates often include performance improvements and new features.
• పర్యావరణ పరిస్థితులు: యూనిట్‌ను తీవ్రమైన ఉష్ణోగ్రతలు, ఎక్కువసేపు ప్రత్యక్ష సూర్యకాంతి లేదా అధిక తేమకు గురిచేయకుండా ఉండండి.

8. ట్రబుల్షూటింగ్

If you encounter issues with your ATOTO S8 Pro, refer to the following common troubleshooting tips:

• Display Issues (Scratches, Frozen Screen, Blurry): Ensure the display module is securely installed with all screws tightened. Loose connections can cause these problems.
• శక్తి లేదు: Check all power connections according to the wiring diagram. Verify vehicle's fuse for the stereo.
• ధ్వని లేదు: Check speaker connections and ensure the volume is not muted or set too low. Verify ampవర్తిస్తే లైఫైయర్ కనెక్షన్లు.
• Connectivity Problems (Bluetooth/WiFi/4G): Ensure antennas are properly connected. For 4G, verify SIM card insertion and activation. For Bluetooth/WiFi, ensure devices are within range and correctly paired/connected.
• కార్‌ప్లే/ఆండ్రాయిడ్ ఆటో కనెక్ట్ కావడం లేదు: Ensure your smartphone is compatible and its operating system is up to date. Try both wired and wireless connections. A system firmware update on the S8 Pro may be required.
• Screen Blocking Vehicle Controls: Due to the floating screen design, in some vehicles, the screen edge might block air vents or buttons. If this is unacceptable, consider alternative ATOTO models with different mounting styles.

For persistent issues, consult the online support resources or contact ATOTO customer service.

9. స్పెసిఫికేషన్లు

10. వారంటీ మరియు మద్దతు

ATOTO offers comprehensive support for its products:

• ఉత్పత్తి సంరక్షణ: Enjoy 12 months of standard product care, extendable by an additional 6 months upon registration.
• సాఫ్ట్‌వేర్ అప్‌డేట్‌లు: Continuous system firmware updates are available via OTA (Over-The-Air) through the FindApps application, ensuring your unit stays current with the latest features and improvements.
• కస్టమర్ మద్దతు: For any inquiries, technical assistance, or warranty claims, please refer to the online resources quick guide or contact ATOTO support directly. Contact information can typically be found on the product online support card or the official ATOTO webసైట్.

Image: Information regarding ATOTO's 12+6 months product care, OTA updates via FindApps, and options to request help, indicating comprehensive customer support.
