1. పరిచయం
The Vimar 19593 Arké Connected IoT Actuator is an electronic control device designed for smart home environments. It features a NO 16 A relay output and supports dual IoT technology: Bluetooth 5.0 for the Vimar VIEW wireless mesh system and Zigbee 3.0 for broader compatibility. This actuator allows for both local control via a physical button and remote control through dedicated applications. It also includes instantaneous power measurement and energy consumption monitoring capabilities, along with an RGB LED for status indication and adjustable intensity.
This manual provides essential information for the safe installation, operation, and maintenance of your Vimar 19593 Arké Connected IoT Actuator.
2. భద్రతా సమాచారం
- విద్యుత్ పరికర వ్యవస్థాపన: Installation must be performed by qualified personnel in compliance with local electrical codes and regulations.
- విద్యుత్ సరఫరా: Ensure the power supply (100-240 V ~ 50/60 Hz) matches the device specifications before installation.
- పవర్ డిస్కనెక్ట్ చేయండి: Always disconnect power at the main circuit breaker before performing any installation, wiring, or maintenance.
- ఇండోర్ ఉపయోగం మాత్రమే: This device is intended for indoor use in dry environments. Do not expose to moisture or extreme temperatures.
- ఓవర్లోడ్ను నివారించండి: Do not exceed the maximum load rating of 16 A for the relay output.
- పిల్లలు మరియు పెంపుడు జంతువులు: పరికరం మరియు దాని భాగాలను పిల్లలు మరియు పెంపుడు జంతువులకు దూరంగా ఉంచండి.
3. ఉత్పత్తి ముగిసిందిview
The Vimar 19593 Arké Connected IoT Actuator is a compact module designed for integration into standard electrical systems. It features a physical button for local control and pairing, and an RGB LED indicator for status feedback.
మూర్తి 1: ముందు view of the Vimar 19593 Arké Connected IoT Actuator. It is a dark gray rectangular module with a small indicator light and a circular button at the bottom.
మూర్తి 2: Close-up of the actuator showing a symbol for wireless connectivity and the control button.
ముఖ్య భాగాలు:
- నియంత్రణ బటన్: Used for local ON/OFF control and initiating the pairing process.
- RGB LED సూచిక: Provides visual feedback on device status, pairing mode, and can be adjusted for intensity.
- రిలే అవుట్పుట్: Connects to the load (e.g., lights, appliances) for switching ON/OFF.
- వైర్లెస్ మాడ్యూల్స్: Integrated Bluetooth 5.0 and Zigbee 3.0 for smart home connectivity.
4. సెటప్
4.1 భౌతిక సంస్థాపన
- పవర్ డిస్కనెక్ట్ చేయండి: Before starting, ensure the main power supply to the installation area is switched off at the circuit breaker.
- వైరింగ్: Connect the actuator according to the provided wiring diagram (typically found on the device itself or in the packaging). Ensure correct connection of live, neutral, and load wires to the appropriate terminals. This device is designed for modular, flush-mounted, or wall-mounted installations.
- సురక్షిత పరికరం: Mount the actuator securely within the electrical box or housing.
- శక్తిని పునరుద్ధరించండి: ఇన్స్టాలేషన్ పూర్తయిన తర్వాత మరియు అన్ని కనెక్షన్లు సురక్షితంగా ఉన్న తర్వాత, సర్క్యూట్ బ్రేకర్ వద్ద పవర్ను పునరుద్ధరించండి.
4.2 యాప్ ఇన్స్టాలేషన్ మరియు జత చేయడం
The Vimar 19593 supports two primary wireless technologies for smart home integration: Bluetooth 5.0 (via Vimar VIEW Wireless app) and Zigbee 3.0 (via compatible Zigbee hubs and apps).
మూర్తి 3: ది విమర్శ VIEW App icon, used for managing the actuator.
- అనువర్తనాన్ని డౌన్లోడ్ చేయండి: డౌన్లోడ్ చేయండి విమర్ VIEW వైర్లెస్ app from your device's app store (for Bluetooth control) or a compatible Zigbee hub app (e.g., Amazon Alexa app for Zigbee).
- ఖాతాను సృష్టించండి: Open the app and create an account if you don't already have one.
- జత చేసే మోడ్ను ప్రారంభించండి: Press and hold the physical control button on the actuator for approximately 5 seconds. The RGB LED will begin to pulse blue, indicating it is in pairing mode.
- యాప్లో పరికరాన్ని జోడించండి: Follow the on-screen instructions in your chosen app to add a new device. The app should detect the Vimar 19593 actuator.
- Select Technology: Within the Vimar VIEW Wireless app, you can switch between Bluetooth and Zigbee modes if needed. For Zigbee, ensure your Zigbee hub is also in pairing mode.
- పూర్తి సెటప్: Assign a name to your device and configure any initial settings as prompted by the app.
5. ఆపరేటింగ్ సూచనలు
5.1 స్థానిక నియంత్రణ
- ఆన్/ఆఫ్: Briefly press the physical control button on the actuator to toggle the connected load ON or OFF.
5.2 యాప్ ద్వారా రిమోట్ కంట్రోల్
Once paired, you can control the actuator remotely using the Vimar VIEW Wireless app (for Bluetooth) or a compatible Zigbee app.
మూర్తి 4: Example of the Vimar app interface showing energy monitoring for connected devices.
- Toggle Load: Open the app, select your Vimar 19593 actuator, and use the virtual button to switch the connected load ON or OFF.
- శక్తి పర్యవేక్షణ: The app provides real-time instantaneous power measurement and tracks consumed energy. This feature allows you to monitor the power usage of the connected appliance.
- RGB LED Adjustment: Adjust the intensity and potentially the color (if supported by the app) of the RGB LED indicator through the app settings.
5.3 వాయిస్ కంట్రోల్ ఇంటిగ్రేషన్
The actuator can be integrated with voice assistants through compatible smart home hubs (e.g., Amazon Alexa for Zigbee). Refer to your voice assistant's setup guide for integration steps.
మూర్తి 5: Illustration of a smart plug (similar to actuator function) being controlled via voice commands and a smartphone app.
6. నిర్వహణ
- శుభ్రపరచడం: Disconnect power before cleaning. Use a soft, dry cloth to wipe the device. Do not use liquid cleaners or abrasive materials.
- ఫర్మ్వేర్ నవీకరణలు: Periodically check the Vimar VIEW Wireless app for available firmware updates to ensure optimal performance and security. Follow the app's instructions for any update procedures.
- సాధారణ తనిఖీలు: Occasionally inspect the device for any signs of damage or loose connections. If any issues are found, disconnect power and consult a qualified electrician.
7. ట్రబుల్షూటింగ్
- పరికరం స్పందించడం లేదు:
- విద్యుత్ సరఫరా యాక్టివ్గా ఉందో లేదో తనిఖీ చేయండి.
- Ensure the device is properly wired.
- If using a Vimar Gateway, confirm it has an active internet (CLOUD) connection, as loss of connection may prevent operation.
- జత చేయడం సమస్యలు:
- Ensure the actuator's LED is pulsing blue, indicating pairing mode.
- Verify your smartphone or Zigbee hub is within range.
- If re-associating, you may need to switch the device to Bluetooth mode via the Vimar Arké app, then back to Zigbee. If this fails, temporarily remove power from the actuator and restore it to attempt a reset before re-pairing.
- LED Not Functioning as Expected (Zigbee Hub):
- When associated with a generic Zigbee hub, direct control over the LED's function and color may be limited. The LED typically reflects the actuator's ON (blue) or OFF (off) state.
- Power Consumption Readings Missing (Zigbee Hub):
- Some Zigbee integrations (e.g., ZHA) might not fully support reading power consumption data from this device. Verify compatibility with your specific Zigbee coordinator and integration.
- ఫ్యాక్టరీ రీసెట్: To perform a factory reset, remove power from the device for a few seconds, then restore it. This may clear all pairing information.
8. స్పెసిఫికేషన్లు
| తయారీదారు | విమర్ |
| మోడల్ సంఖ్య | 19593 |
| ఉత్పత్తి కొలతలు | 4.9 x 2.22 x 5.01 సెం.మీ |
| బరువు | 40 గ్రాములు |
| రంగు | బూడిద రంగు |
| వాల్యూమ్tage | 100-240 వోల్ట్లు AC |
| ఫ్రీక్వెన్సీ | 50/60 Hz |
| రిలే అవుట్పుట్ | NO 16 A |
| వైర్లెస్ టెక్నాలజీ | Bluetooth 5.0, Zigbee 3.0 |
| బ్యాటరీలు అవసరం | నం |
| మూలం దేశం | ఇటలీ |
9. వారంటీ
For information regarding the warranty period and terms for your Vimar 19593 Arké Connected IoT Actuator, please refer to the official Vimar website or the warranty documentation included with your purchase. Warranty policies may vary by region and retailer.
10. మద్దతు
For additional instructions, tutorials, and technical support, please visit the official Vimar support webసైట్:
You can also contact Vimar customer service directly for assistance with product inquiries, troubleshooting, or warranty claims.
