1. ముఖ్యమైన భద్రతా సూచనలు
ఉపకరణాన్ని ఉపయోగించే ముందు దయచేసి అన్ని సూచనలను జాగ్రత్తగా చదవండి. భవిష్యత్తు సూచన కోసం ఈ మాన్యువల్ని ఉంచండి.
- విద్యుత్ భద్రత: Ensure the appliance is connected to a properly grounded outlet. Do not immerse the appliance, cord, or plug in water or other liquids.
- హాట్ ఆయిల్ ప్రమాదం: Oil and fat can reach very high temperatures. Exercise extreme caution to prevent burns. Never move the fryer when it contains hot oil.
- అగ్ని ప్రమాదం: Do not leave the fryer unattended during operation. In case of fire, do not use water; smother flames with a fire blanket or suitable extinguisher.
- పిల్లలు మరియు పెంపుడు జంతువులు: Keep the appliance out of reach of children and pets, especially during operation and cooling.
- వెంటిలేషన్: Ensure adequate ventilation when operating the fryer.
- నిర్వహణ: Disconnect from power supply before cleaning or maintenance. Allow the appliance to cool completely before handling.
2. ఉత్పత్తి ముగిసిందిview
The NOVY 3711 is a built-in stainless steel fryer designed for integration into your kitchen countertop. It features intuitive button control for temperature settings and a cold zone for improved oil longevity.
- మెటీరియల్: High-quality stainless steel construction.
- నియంత్రణ: Simple button control for ease of use.
- ఉష్ణోగ్రత: గరిష్ట ఉష్ణోగ్రత 180°C.
- శీతల మండలం: Helps to collect food debris at the bottom, preventing premature oil degradation.
- శుభ్రపరచడం సులభం: నేరుగా శుభ్రపరచడం మరియు నిర్వహణ కోసం రూపొందించబడింది.
మూర్తి 2.1: టాప్ view of the NOVY 3711 Fryer, showing the control knob, indicator light, and frying basket in place.
Figure 2.2: The NOVY 3711 Fryer integrated into a kitchen countertop, shown with its protective stainless steel cover closed, adjacent to a cooking hob.
3. సంస్థాపన మరియు సెటప్
The NOVY 3711 is a built-in appliance requiring professional installation. Ensure all electrical connections comply with local regulations.
3.1 ఉత్పత్తి కొలతలు
Figure 3.1: Overall dimensions of the NOVY 3711 Fryer. Dimensions are approximately 35 cm (width) x 55 cm (depth) x 25 cm (height).
3.2 Countertop Cutout Dimensions
A precise cutout in the countertop is necessary for proper installation. Refer to the diagram below for required dimensions.
Figure 3.2: Required countertop cutout dimensions for the NOVY 3711 Fryer. The cutout should be approximately 270 mm (E) x 475 mm (F). A minimum distance of 50 mm (X) from the back edge is indicated.
3.3 ఎలక్ట్రికల్ కనెక్షన్
The appliance requires a 2000 Watt power supply. Ensure the electrical circuit can support this load. Connection must be performed by a qualified electrician.
3.4 ప్రారంభ ఉపయోగం
- Before first use, clean all removable parts (basket, oil container) with warm soapy water. Rinse thoroughly and dry completely.
- Ensure the oil container is correctly positioned within the appliance.
- Fill the oil container with suitable frying oil or fat up to the indicated maximum level. Do not overfill.
4. ఆపరేటింగ్ సూచనలు
Follow these steps for safe and effective operation of your NOVY 3711 Fryer.
- పవర్ ఆన్: Ensure the fryer is plugged in and the main power switch (if applicable) is on.
- సెట్ ఉష్ణోగ్రత: Turn the control knob to the desired frying temperature. The maximum temperature is 180°C. An indicator light will illuminate to show the heating element is active.
- ముందుగా వేడి చేయడం: Allow the oil to preheat to the set temperature. This may take several minutes. The indicator light will turn off once the temperature is reached and cycle on/off during operation to maintain temperature.
- వేయించడం: Carefully lower the food into the hot oil using the frying basket. Do not overload the basket, as this can lower oil temperature and result in soggy food.
- పర్యవేక్షణ: Supervise the frying process. Adjust temperature if necessary.
- ఆహారాన్ని తొలగించడం: Once cooked, lift the basket and allow excess oil to drain. Place food on paper towels to absorb remaining oil.
- పవర్ ఆఫ్: After use, turn the control knob to the 'off' position and unplug the appliance from the power supply. Allow the oil to cool completely before handling.
4.1 Cold Zone Function
The cold zone at the bottom of the oil container helps to collect food particles that fall off during frying. This prevents them from burning and contaminating the oil, extending the oil's lifespan and maintaining food quality.
5. శుభ్రపరచడం మరియు నిర్వహణ
Regular cleaning ensures optimal performance and extends the life of your fryer. Always ensure the appliance is unplugged and completely cool before cleaning.
- చమురు పారవేయడం: Once the oil has cooled, carefully remove the oil container. Filter the oil for reuse or dispose of it responsibly according to local regulations.
- శుభ్రపరిచే భాగాలు: The frying basket and oil container are removable and can be washed with warm soapy water. For stubborn residue, a non-abrasive cleaner can be used. Rinse thoroughly and dry completely.
- ఉపకరణం బాహ్య భాగం: బయటి స్టెయిన్లెస్ స్టీల్ ఉపరితలాలను ప్రకటనతో తుడవండిamp వస్త్రం మరియు తేలికపాటి డిటర్జెంట్. రాపిడి క్లీనర్లు లేదా స్కౌరింగ్ ప్యాడ్లను ఉపయోగించవద్దు, ఎందుకంటే ఇవి ఉపరితలంపై గీతలు పడతాయి.
- కోల్డ్ జోన్ క్లీనింగ్: Pay special attention to cleaning the cold zone area to remove accumulated food debris.
- నిల్వ: Once clean and dry, reassemble the fryer. If not in regular use, cover the appliance to protect it from dust.
6. ట్రబుల్షూటింగ్
If you encounter issues with your NOVY 3711 Fryer, refer to the following common problems and solutions.
| సమస్య | సాధ్యమైన కారణం | పరిష్కారం |
|---|---|---|
| ఫ్రైయర్ వేడెక్కదు. | ప్లగిన్ చేయబడలేదు; పవర్ లేదాtage; faulty connection; thermostat issue. | Check power plug and outlet. Verify circuit breaker. If problem persists, contact qualified service personnel. |
| నూనె కావలసిన ఉష్ణోగ్రతకు చేరుకోలేదు. | Incorrect temperature setting; too much food added at once; insufficient preheating time. | Ensure correct temperature is set. Allow sufficient preheating. Fry smaller batches of food. |
| ఆహారం తడిగా లేదా జిడ్డుగా ఉంటుంది. | నూనె ఉష్ణోగ్రత చాలా తక్కువగా ఉంది; బుట్టలో చాలా ఆహారం ఉంది; నూనె మార్చాలి. | Ensure oil is at correct temperature. Do not overload basket. Change oil if it is old or discolored. |
| పొగ లేదా మండే వాసన. | Food particles burning in oil; oil too old or overheated. | Turn off immediately. Allow to cool. Clean cold zone and change oil. Ensure proper ventilation. |
For issues not listed here or if troubleshooting steps do not resolve the problem, contact NOVY customer support or a qualified service technician.
7. సాంకేతిక లక్షణాలు
- మోడల్: NOVY 3711
- రకం: Built-in Fryer
- మెటీరియల్: స్టెయిన్లెస్ స్టీల్
- కొలతలు (L x W x H): సుమారు 35 సెం.మీ x 55 సెం.మీ x 25 సెం.మీ.
- బరువు: 8 కిలోలు
- శక్తి: 2000 వాట్స్
- గరిష్ట ఉష్ణోగ్రత: 180°C
- నియంత్రణ రకం: బటన్ / నాబ్
8. వారంటీ మరియు మద్దతు
Information regarding the warranty period and specific terms for the NOVY 3711 Fryer is not provided within this manual. Please refer to the warranty card included with your purchase or contact your retailer or NOVY customer service directly for detailed warranty information and support options.
For technical assistance, spare parts, or service inquiries, please contact the official NOVY support channels.
