పరిచయం
Thank you for choosing the Meaco Dry Arete® One 20L Dehumidifier and HEPA Air Purifier. This 2-in-1 appliance is designed to effectively control humidity levels in your home while simultaneously purifying the air. It is engineered for quiet operation and energy efficiency, making it an ideal solution for managing condensation, mold, and dampness, and improving indoor air quality by filtering out common allergens and particles.
This manual provides essential information for the safe and efficient use, maintenance, and troubleshooting of your new Meaco appliance. Please read it thoroughly before operation and retain it for future reference.
ముందు view of the Meaco Dry Arete One 20L Dehumidifier, showcasing its sleek white design and integrated water tank window.
భద్రతా సమాచారం
To ensure safe operation and prevent damage to the unit or injury to yourself and others, please observe the following safety precautions:
- ప్లేస్మెంట్: Always place the unit on a stable, level surface. Ensure adequate clearance around the unit for proper airflow (at least 20cm from walls or furniture).
- విద్యుత్ సరఫరా: Connect the unit only to a grounded power outlet with the correct voltage as specified on the rating label. Do not overload the power outlet.
- పవర్ కార్డ్: Do not damage, modify, or place heavy objects on the power cord. Do not pull the power cord to disconnect the plug. Always grasp the plug firmly.
- నీటి ట్యాంక్: Do not drink the water collected in the tank. Empty the water tank regularly.
- పిల్లలు మరియు పెంపుడు జంతువులు: Keep the appliance out of reach of children and pets. Do not allow children to play with the unit.
- నిర్వహణ: Always unplug the unit before cleaning or performing any maintenance. Do not attempt to repair the unit yourself; contact qualified service personnel.
- వినియోగ వాతావరణం: Do not use the unit in bathrooms, laundry rooms, or other excessively wet areas where water may splash onto the unit. Do not expose the unit to direct sunlight or extreme temperatures.
- రిఫ్రిజెరాంట్: This appliance contains R290 refrigerant. Allow the unit to stand upright for at least 6 hours before initial use or after transport to allow the refrigerant to settle.
ఉత్పత్తి భాగాలు
Familiarize yourself with the main components of your Meaco Dry Arete® One 20L dehumidifier:
- నియంత్రణ ప్యానెల్: Located on the top surface, with touch-sensitive buttons and a digital display.
- ఎయిర్ అవుట్లెట్: Top grille for purified and dehumidified air release.
- గాలి తీసుకోవడం: Side grille for drawing in air.
- నీటి ట్యాంక్: Front-loading, removable tank for collected water. Features a handle for easy carrying.
- నిరంతర మురుగునీటి అవుట్లెట్: Located at the back for connecting a hose for continuous drainage (hose not included).
- HEPA Filter Compartment: Located behind the air intake grille.
- కాస్టర్లు: Hidden wheels at the base for easy movement.
- క్యారీయింగ్ హ్యాండిల్: Retractable handle on top for portability.
ఎగువ కోణం view of the dehumidifier with its retractable carrying handle extended, showing the control panel.
వెనుక view of the dehumidifier, illustrating the power cord and the side air intake grille.
సెటప్
Follow these steps for initial setup of your dehumidifier:
- అన్ప్యాకింగ్: యూనిట్ను దాని ప్యాకేజింగ్ నుండి జాగ్రత్తగా తొలగించండి. భవిష్యత్తులో నిల్వ లేదా రవాణా కోసం ప్యాకేజింగ్ను ఉంచండి.
- రిఫ్రిజెరాంట్ సెటిల్లింగ్: Place the dehumidifier upright in its desired location. Allow it to stand undisturbed for a minimum of 6 గంటలు before plugging it in. This allows the refrigerant gas to settle, ensuring optimal performance and longevity.
- ప్లేస్మెంట్: Position the unit in an area where air can circulate freely around it. Avoid placing it directly against walls or furniture. The hidden castors allow for easy repositioning.
- పవర్ కనెక్షన్: Once the settling period is complete, firmly insert the power plug into a suitable grounded electrical outlet.
- HEPA Filter Installation (if not pre-installed): Open the filter compartment (usually behind the side air intake grille). Remove the HEPA filter from its protective plastic bag and insert it correctly into the compartment. Close the compartment cover securely.
వైపు view of the dehumidifier, highlighting the air intake grille where the HEPA filter is located.
ఆపరేటింగ్ సూచనలు
Your Meaco Dry Arete® One 20L features an intuitive control panel with various modes to suit your needs.
A hand interacting with the touch control panel of the Meaco Dry Arete One 20L dehumidifier.
Graphic illustrating the smart features of the Meaco Dry Arete One 20L, including One Touch Laundry Mode, Purification Mode, Smart Humidity Mode, and Night Mode.
నియంత్రణ ప్యానెల్ విధులు:
- పవర్ బటన్ (⏻ ⏻ తెలుగు): యూనిట్ను ఆన్ లేదా ఆఫ్ చేయడానికి నొక్కండి.
- తేమ సెట్టింగ్ బటన్ (💧): Adjusts the target humidity level (e.g., 40%, 50%, 60%). The unit will operate until this level is reached.
- Laundry Mode Button (👕): Activates a dedicated mode for drying laundry. The unit will run continuously for 6 hours at a high fan speed to efficiently dry clothes, then automatically shut off.
- రాత్రి మోడ్ బటన్ (🌛): Dims the display lights and reduces fan speed for quieter operation during sleep.
- Purification Mode Button (✨): Activates the air purification function using the HEPA filter, without active dehumidification.
- ప్రదర్శన: Shows the current humidity level or selected settings.
ఆపరేటింగ్ మోడ్లు:
- స్మార్ట్ తేమ మోడ్: The unit automatically maintains your set humidity level, turning on and off as needed. This is the most energy-efficient mode for general use.
- లాండ్రీ మోడ్: Ideal for drying clothes indoors. Place the laundry near the unit and activate this mode. The unit will run for a set period to remove moisture from the air, aiding in faster drying.
- రాత్రి మోడ్: For undisturbed sleep, select this mode to reduce operational noise and dim indicators.
- శుద్దీకరణ మోడ్: When humidity control is not needed, use this mode to continuously filter the air using the H13 HEPA filter, removing dust, pollen, pet dander, and other allergens.
Graphic highlighting the unit's ability to extract up to 14 liters of water per day and its suitability for various home areas, with auto shutoff at 4.8L tank capacity.
నిర్వహణ
క్రమం తప్పకుండా నిర్వహణ మీ డీహ్యూమిడిఫైయర్ యొక్క దీర్ఘాయువు మరియు సమర్థవంతమైన ఆపరేషన్ను నిర్ధారిస్తుంది.
1. వాటర్ ట్యాంక్:
- ఖాళీ చేయడం: When the water tank is full, the unit will automatically stop and an indicator light will illuminate. Carefully pull out the front-loading water tank using its handle.
- పారవేయడం: Dispose of the collected water. Do not use it for drinking or watering plants.
- శుభ్రపరచడం: Clean the water tank regularly with mild soap and water to prevent mold and mildew growth. Rinse thoroughly.
- Reinsertion: Slide the clean, empty tank back into the unit until it clicks into place.
2. Air Filters:
Your unit has two filters: a washable dust filter and a replaceable H13 HEPA filter.
- డస్ట్ ఫిల్టర్: This filter is washable. Remove it from the unit (usually located behind the air intake grille). Clean it with a soft brush or vacuum cleaner. If heavily soiled, wash with warm, soapy water, rinse thoroughly, and allow to air dry completely before reinserting. Clean every 2-4 weeks depending on usage.
- HEPA ఫిల్టర్: The H13 HEPA filter is not washable and should be replaced every 6-12 months, or more frequently if the unit is used in a dusty environment or if you notice a decrease in air purification effectiveness. Refer to the manufacturer's website for replacement filters.
3. బాహ్య క్లీనింగ్:
- శుభ్రపరచడం: యూనిట్ యొక్క బాహ్య భాగాన్ని మృదువైన, డితో తుడవండిamp కఠినమైన రసాయనాలు, రాపిడి క్లీనర్లు లేదా ద్రావకాలను ఉపయోగించవద్దు, ఎందుకంటే ఇవి ఉపరితలాన్ని దెబ్బతీస్తాయి.
- నిల్వ: If storing the unit for an extended period, ensure it is clean and dry. Empty the water tank and store the unit upright in a cool, dry place.
Graphic detailing how the unit purifies and protects, including keeping dampness from damaging homes, protecting surfaces, repelling mold, and the H13 HEPA filter's effectiveness against dust, pet dander, spores, and allergens.
ట్రబుల్షూటింగ్
మీ డీహ్యూమిడిఫైయర్తో మీరు సమస్యలను ఎదుర్కొంటే, సాధారణ సమస్యలు మరియు పరిష్కారాల కోసం క్రింది పట్టికను చూడండి.
| సమస్య | సాధ్యమైన కారణం | పరిష్కారం |
|---|---|---|
| యూనిట్ ఆన్ చేయబడలేదు. | No power supply; power cord not plugged in; power outage. | Check power plug and outlet; ensure power is available. |
| నీటిని సేకరించలేదు. | Humidity level is too low; water tank full or incorrectly inserted; temperature too low. | Adjust target humidity lower; empty and reinsert tank; ensure room temperature is above 5°C. |
| యూనిట్ ధ్వనించే ఉంది. | యూనిట్ సమతల ఉపరితలంపై లేదు; ఎయిర్ ఫిల్టర్ మూసుకుపోయింది; ఫ్యాన్ అవరోధం. | Place on a flat surface; clean or replace air filter; check for obstructions. |
| గాలి ప్రసరణ బలహీనంగా ఉంది. | Air filter clogged; air intake/outlet blocked. | Clean or replace air filter; ensure no obstructions around air intake/outlet. |
| యూనిట్ నిరంతరం నడుస్తుంది. | Target humidity not reached; room is too large or too humid. | Ensure doors/windows are closed; consider a larger capacity unit for very large spaces. |
స్పెసిఫికేషన్లు
Technical specifications for the Meaco Dry Arete® One 20L Dehumidifier and HEPA Air Purifier:
| ఫీచర్ | వివరాలు |
|---|---|
| బ్రాండ్ | మీకో |
| మోడల్ సంఖ్య | Arete 20L (AreteOne-20L-86m²) |
| డీహ్యూమిడిఫికేషన్ సామర్థ్యం | 20 లీటర్లు/రోజు |
| వాటర్ ట్యాంక్ వాల్యూమ్ | 4.8 Litres (approx. 1.27 Gallons) |
| విద్యుత్ వినియోగం | 204 వాట్స్ |
| కొలతలు (L x W x H) | 27.2 x 36.6 x 61.8 సెం.మీ |
| బరువు | 15 కిలోలు |
| సిఫార్సు చేయబడిన అంతస్తు ప్రాంతం | 80 చదరపు మీటర్లు |
| గాలి వడపోత | H13 HEPA ఫిల్టర్ |
| శబ్దం స్థాయి | 40 dB (సుమారుగా) |
| ఆటోమేటిక్ షటాఫ్ | అవును (ట్యాంక్ నిండినప్పుడు) |
| ప్రత్యేక లక్షణాలు | Child Safety Lock, Laundry Mode, Adjustable Humidity Control, Continuous Drainage Option |
వారంటీ మరియు మద్దతు
Meaco is committed to providing high-quality products and excellent customer service.
వారంటీ సమాచారం:
The Meaco Dry Arete® One 20L Dehumidifier comes with a comprehensive ఐదు సంవత్సరాల వారంటీ as standard. This warranty covers defects in materials and workmanship under normal use. Please retain your proof of purchase for warranty claims.
The Meaco Dry Arete One 20L has received the T3 Platinum Award, recognizing its outstanding performance and design.
Recognized as a 'Best Buy' by Which? for Dehumidifiers in November 2021, affirming its quality and value.
కస్టమర్ మద్దతు:
For technical assistance, warranty claims, or to purchase replacement parts (such as HEPA filters), please visit the official Meaco website or contact their customer service department. Contact details can typically be found on the Meaco webసైట్ లేదా ఉత్పత్తి ప్యాకేజింగ్లో.
