థామ్సన్ WS602DUO బ్లూటూత్ బుక్‌షెల్ఫ్ స్పీకర్స్ యూజర్ మాన్యువల్

1. పరిచయం

Thank you for choosing the THOMSON WS602DUO Bluetooth Bookshelf Speakers. This system combines elegant design with acoustic performance and versatile connectivity options. Whether used wirelessly via Bluetooth or connected to a turntable, micro-chain system, or PC, these speakers are designed to integrate seamlessly into any interior while delivering high-quality stereo sound.

This manual provides essential information for the proper setup, operation, and maintenance of your speakers. Please read it thoroughly before use and retain it for future reference.

Image 1.1: The THOMSON WS602DUO speakers, remote control, and a smartphone demonstrating wireless connectivity.

ప్యాకేజీ విషయాలు:

• 2 x THOMSON WS602DUO Bookshelf Speakers
• 1 x రిమోట్ కంట్రోల్
• 1 x ఆప్టికల్ కేబుల్
• 1 x పవర్ కేబుల్
• వినియోగదారు మాన్యువల్

2. సెటప్

2.1 స్పీకర్ ప్లేస్‌మెంట్

For optimal sound quality, place the two speakers on a stable, flat surface, such as a bookshelf or table, ensuring they are equidistant from your listening position. Avoid placing them in enclosed spaces that might obstruct sound projection.

చిత్రం 2.1: ఉదాample placement of a single speaker next to a television.

2.2 పవర్ కనెక్షన్

1. Connect the provided power cable to the main speaker's power input.
2. పవర్ కేబుల్‌ను ప్రామాణిక వాల్ అవుట్‌లెట్‌లోకి ప్లగ్ చేయండి.
3. Ensure the power switch on the main speaker is in the 'ON' position.

2.3 ఆడియో సోర్స్ కనెక్షన్లు

The WS602DUO speakers offer multiple connectivity options:

• బ్లూటూత్ 5.0: For wireless audio streaming from compatible devices like smartphones, tablets, or laptops.
• RCA Inputs (x2): For connecting devices such as turntables, CD players, or micro-chain systems.
• ఆప్టికల్ ఇన్‌పుట్: For connecting digital audio sources like televisions or game consoles using the supplied optical cable.

Connecting via RCA:

1. Identify the RCA input ports on the rear of the main speaker.
2. Connect your audio source (e.g., turntable, micro-chain) to the RCA inputs using appropriate RCA cables (not always included).

Image 2.2: Speakers connected to a micro-chain system via RCA.

ఆప్టికల్ ద్వారా కనెక్ట్ చేస్తోంది:

1. Connect one end of the supplied optical cable to the optical output of your device (e.g., TV).
2. Connect the other end to the optical input port on the rear of the main speaker.

బ్లూటూత్ ద్వారా జత చేయడం:

1. స్పీకర్లు ఆన్ చేయబడ్డాయని నిర్ధారించుకోండి.
2. Select Bluetooth as the input source on the speakers (refer to Section 3.2). The Bluetooth indicator will flash, indicating pairing mode.
3. On your Bluetooth-enabled device, go to Bluetooth settings and search for available devices.
4. Select "THOMSON WS602DUO" from the list.
5. Once connected, the Bluetooth indicator on the speakers will glow steadily.

Image 2.3: Speakers ready for Bluetooth audio streaming with a smartphone.

3. ఆపరేటింగ్ సూచనలు

3.1 పవర్ ఆన్/ఆఫ్

Use the power switch located on the rear of the main speaker to turn the system on or off. Alternatively, the remote control can be used to put the speakers into standby mode.

3.2 ఇన్‌పుట్ మూలాన్ని ఎంచుకోవడం

Press the 'Source' button on the remote control or the control panel on the main speaker to cycle through the available input modes: Bluetooth, RCA 1, RCA 2, and Optical.

3.3 వాల్యూమ్ నియంత్రణ

Adjust the volume using the '+' and '-' buttons on the remote control or the rotary knob on the main speaker. Ensure the volume on your connected audio source is also set to an appropriate level.

3.4 రిమోట్ కంట్రోల్ విధులు

The included remote control allows for convenient operation of your speakers:

• శక్తి: Turns the speakers on/off (standby).
• మూలం: Cycles through input modes (Bluetooth, RCA, Optical).
• వాల్యూమ్ +/-: మాస్టర్ వాల్యూమ్‌ను సర్దుబాటు చేస్తుంది.
• మ్యూట్: ఆడియో అవుట్‌పుట్‌ను మ్యూట్ చేస్తుంది లేదా అన్‌మ్యూట్ చేస్తుంది.
• Play/Pause, Next/Previous Track: (Bluetooth mode only) Controls media playback on the connected Bluetooth device.

4. నిర్వహణ

4.1 శుభ్రపరచడం

To clean the speaker cabinets, use a soft, dry cloth. Do not use liquid cleaners, aerosols, or abrasive materials, as these may damage the finish. For the speaker grilles, a soft brush or vacuum cleaner with a brush attachment can be used to gently remove dust.

4.2 నిల్వ

When not in use for extended periods, store the speakers in a cool, dry place, away from direct sunlight and extreme temperatures. It is recommended to disconnect them from the power supply.

5. ట్రబుల్షూటింగ్

If you encounter any issues with your THOMSON WS602DUO speakers, please refer to the following common problems and solutions:

• ధ్వని లేదు:
  • Ensure the speakers are powered on and the volume is not muted or set too low.
  • Verify that the correct input source (Bluetooth, RCA, Optical) is selected.
  • Check all cable connections (power, RCA, optical) are secure.
  • Ensure the volume on your audio source device is also turned up.
• బ్లూటూత్ జత చేయడం సమస్యలు:
  • Make sure the speakers are in Bluetooth pairing mode (indicator flashing).
  • మీ పరికరం యొక్క బ్లూటూత్ ప్రారంభించబడిందని మరియు పరిధిలో (సాధారణంగా 10 మీటర్ల వరకు) ఉందని నిర్ధారించుకోండి.
  • Try unpairing and re-pairing the speakers from your device's Bluetooth settings.
  • Restart both the speakers and your Bluetooth device.
• వక్రీకరించబడిన లేదా పేలవమైన ధ్వని నాణ్యత:
  • Check if the audio source volume is too high, causing distortion. Reduce the source volume.
  • అన్ని కేబుల్‌లు సరిగ్గా కనెక్ట్ అయ్యాయని మరియు పాడవకుండా చూసుకోండి.
  • If using Bluetooth, move closer to the speakers to avoid interference.
  • Test with a different audio source or cable to isolate the problem.

6. స్పెసిఫికేషన్లు

7. వారంటీ మరియు మద్దతు

7.1 వారంటీ సమాచారం

The THOMSON WS602DUO speakers come with a limited warranty. Please refer to the warranty card included in your package or contact your retailer for specific terms and conditions regarding the warranty period and coverage.

7.2 కస్టమర్ మద్దతు

For technical assistance, troubleshooting beyond the scope of this manual, or warranty claims, please contact THOMSON customer support or your authorized dealer. Contact information can typically be found on the manufacturer's official webసైట్ లేదా మీ కొనుగోలు రసీదులో.
