ARRMA 1/8 Notorious 4X4 6S BLX BRUSHLESS V6 Stunt Truck RTR Instruction Manual

1. భద్రతా సమాచారం

హెచ్చరిక: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in damage to the product, personal property, and cause serious injury. This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability.

Failure to operate this Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC.

The product manual contains instructions for safety, operation, and maintenance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.

2. పెట్టెలో ఏముంది

The ARRMA Notorious 6S BLX 4X4 1/8 Scale Stunt Truck RTR package includes the following components:

• 1x NOTORIOUS 6S BLX 4X4 1/8 Scale Stunt Truck RTR
• 1x Spektrum Firma 150A Smart V2 Brushless 6S ESC with updated B5.12 firmware and IC5 connectors
• 1x Spektrum Firma 4074 2050Kv Brushless Motor
• 1x Spektrum SLT3 2.4GHz Transmitter
• 1x Spektrum SR315 DSMR 3-Channel Dual Protocol Sport Receiver
• 1x Spektrum S665 20kg Waterproof Metal-Geared Digital Servo
• 1x 25T Spline Aluminum Servo Horn
• 4x AA Transmitter Batteries
• 1x Molded Hand Tools
• 1x ఇన్స్ట్రక్షన్ మాన్యువల్ (ఈ డాక్యుమెంట్)

3. Items Required for Operation (Not Included)

To operate your ARRMA Notorious Stunt Truck, you will need to supply the following items:

• బ్యాటరీలు: One 4S 14.8V LiPo battery, one 6S 22.2V LiPo battery, two 2S 7.4V LiPo batteries, or two 3S 11.1V LiPo batteries. Ensure batteries are IC5 compatible.
• ఛార్జర్: A compatible LiPo battery charger.

The battery tray maximum dimensions are 158 x 48 x 70mm (6.22 x 1.89 x 2.76 inches).

This image illustrates the types of batteries and charger required for the ARRMA Notorious truck, which are not included in the package. It shows options for 4S or 6S LiPo batteries, or combinations of 2S or 3S LiPo batteries, along with a generic charger.

4. సెటప్

4.1 బ్యాటరీ ఇన్‌స్టాలేషన్

1. వాహనం యొక్క పవర్ స్విచ్ ఆఫ్ స్థానంలో ఉందని నిర్ధారించుకోండి.
2. Remove the body shell to access the battery compartment.
3. Place the charged LiPo battery(ies) into the battery tray, ensuring they fit within the maximum dimensions.
4. Secure the battery(ies) using the provided straps or retention system.
5. Connect the battery(ies) to the ESC using the IC5 connectors. Ensure correct polarity.

4.2 ట్రాన్స్మిటర్ సెటప్

1. Install the four AA batteries into the Spektrum SLT3 transmitter.
2. Turn on the transmitter. The LED indicator should illuminate.
3. Ensure the throttle and steering trims are centered.

This image displays the Spektrum SLT3 2.4GHz Transmitter and the Spektrum SR315 DSMR 3-Channel Dual Protocol Sport Receiver, essential components for controlling the RC truck.

4.3 ప్రారంభ తనిఖీలు

1. With the transmitter on, turn on the vehicle's power switch.
2. Verify that the steering responds correctly to transmitter input (left turns left, right turns right). Adjust steering reverse if necessary.
3. Verify that the throttle responds correctly (forward for forward, reverse for reverse).
4. Perform a range check in an open area to ensure reliable signal reception.

5. ఆపరేషన్

5.1 Driving Guidelines

• Always operate your RC truck in a safe, open area away from people, pets, and obstacles.
• Avoid operating in wet conditions to prevent damage to electronics.
• వాహనం యొక్క ప్రతిస్పందనతో మిమ్మల్ని పరిచయం చేసుకోవడానికి సున్నితమైన థొరెటల్ ఇన్‌పుట్‌లతో ప్రారంభించండి.
• The Notorious is designed for stunt driving. Practice stunts in a controlled environment.

This image shows the ARRMA Notorious RC truck in action, kicking up dust as it drives on a loose dirt surface, demonstrating its off-road capability.

The ARRMA Notorious RC truck is captured mid-stunt, driving vertically up a wooden barrier, highlighting its robust design and stunt capabilities.

5.2 Power System Considerations

• The vehicle can be operated with 4S or 6S LiPo power. 4S provides manageable power for less experienced drivers.
• Using 6S LiPo will provide maximum power for advanced bashing and stunts.
• మానిటర్ బ్యాటరీ వాల్యూమ్tage during operation and stop when the low voltage cutoff (LVC) is activated to prevent over-discharge.

This dynamic shot shows the ARRMA Notorious RC truck accelerating rapidly, creating a significant dust cloud behind it, indicative of its powerful brushless motor system.

The ARRMA Notorious RC truck is captured mid-air, performing a jump over a dirt mound, showcasing its suspension travel and ability to handle rough terrain and aerial maneuvers.

6. నిర్వహణ

Regular maintenance is crucial for the longevity and performance of your ARRMA Notorious truck.

6.1 పోస్ట్-రన్ తనిఖీలు

• Inspect for any loose screws, nuts, or bolts. Tighten as necessary.
• Check the wheels and tires for damage or wear.
• Clean any dirt or debris from the chassis, motor, and suspension components.
• Inspect suspension arms, shock absorbers, and linkages for damage.

This image provides an underside view of the ARRMA Notorious RC truck, highlighting the robust chassis with 'EXB' (Extreme Bash) upgrades and the layout of the drivetrain and suspension components.

6.2 ఆవర్తన నిర్వహణ

• అవకలన నిర్వహణ: Periodically inspect and re-grease the differential gears. Refer to the detailed manual for specific procedures.
• షాక్ అబ్జార్బర్లు: Check for leaks and ensure smooth operation. Replace shock oil as needed.
• మోటార్ మరియు ESC: Keep the motor free of debris. Ensure the ESC fan is clear and functional.
• బేరింగ్లు: Inspect bearings for smooth rotation and replace any that feel rough.

This close-up image details the internal chassis components of the ARRMA Notorious, including the prominent red anodized driveshafts, which are part of the robust drivetrain system.

This image displays a set of differential gears and shims, components critical for the truck's drivetrain and power distribution, indicating parts that may require maintenance or replacement.

ఒక వివరణాత్మక view of the ARRMA Notorious RC truck's suspension system, featuring the robust shock absorbers and control arms, designed for absorbing impacts and maintaining stability.

7. ట్రబుల్షూటింగ్

ఈ విభాగం మీరు ఎదుర్కొనే సాధారణ సమస్యలకు పరిష్కారాలను అందిస్తుంది.

For more detailed troubleshooting, refer to the complete manual or contact ARRMA support.

8. స్పెసిఫికేషన్లు

Key specifications for the ARRMA Notorious 6S BLX 4X4 1/8 Scale Stunt Truck RTR:

• ఉత్పత్తి కొలతలు: 25.7 x 13.6 x 21.3 అంగుళాలు
• వస్తువు బరువు: 21.8 పౌండ్లు
• మోడల్ సంఖ్య: ARA8611V6T2
• తయారీదారు: హారిజోన్ హాబీ
• సిఫార్సు చేసిన వయస్సు: 0 - 4 సంవత్సరాలు (Note: This is a manufacturer's general recommendation; direct adult supervision is required for young children due to the nature of the product.)
• మొదట అందుబాటులో ఉన్నవి: నవంబర్ 27, 2024

ముందు వైపు view of the ARRMA Notorious 4X4 6S BLX BRUSHLESS V6 Stunt Truck, showcasing its blue body with a yellow front hood and aggressive off-road tires.

This image features two ARRMA Notorious 6S V6 4X4 BLX RTR Brushless RC Stunt Trucks, one in blue and one in black, parked side-by-side, illustrating the available color options.

9. వారంటీ మరియు మద్దతు

For warranty information and technical support, please refer to the official ARRMA website or contact Horizon Hobby customer service. Keep your proof of purchase for any warranty claims.

Official ARRMA Webసైట్: www.arrma-rc.com

Horizon Hobby Support: www.horizonhobby.com/support
