MINIX B21 Wireless HDMI Adapter User Manual

పరిచయం

The MINIX B21 Wireless HDMI Adapter provides a seamless solution for transmitting high-definition video and audio wirelessly from your USB-C enabled devices to an HDMI display. This plug-and-play system eliminates the need for long cables, offering flexibility and convenience for various applications including presentations, home entertainment, and multi-screen expansion. It supports 1080p Full HD resolution at 60Hz and features a wireless range of up to 50 meters (164 feet).

ప్యాకేజీ విషయాలు

క్రింద జాబితా చేయబడిన అన్ని వస్తువులు మీ ప్యాకేజీలో చేర్చబడ్డాయని ధృవీకరించండి:

• వైర్‌లెస్ HDMI ట్రాన్స్‌మిటర్ (TX) x 2
• వైర్‌లెస్ HDMI రిసీవర్ (RX) x 1
• USB కేబుల్ (టైప్-C నుండి A) x 1
• వినియోగదారు మాన్యువల్ x 1
• Product Packaging x 1

Image: Contents of the MINIX B21 Wireless HDMI Adapter package, showing two transmitters, one receiver, a USB-C to A cable, and the user manual.

ఉత్పత్తి ముగిసిందిview

The MINIX B21 system consists of two main components: the Transmitter (TX) and the Receiver (RX).

ట్రాన్స్మిటర్ (TX)

The Transmitter (TX) connects to your source device (e.g., laptop, smartphone, tablet) via a USB-C port. It captures the video and audio signal and transmits it wirelessly to the Receiver. Each TX unit features an indicator light and a function button.

Image: Diagram illustrating the Transmitter (TX) connecting to USB-C output devices like phones, iPads, and laptops, and the Receiver (RX) connecting to HDMI input devices such as projectors, monitors, and HDTVs.

రిసీవర్ (RX)

The Receiver (RX) connects to your display device (e.g., TV, monitor, projector) via an HDMI port. It receives the wireless signal from the TX unit and outputs the video and audio. The RX unit requires external power, typically supplied via a USB-C port connected to a power adapter (5V, current above 2A).

సెటప్ సూచనలు

Follow these steps to set up your MINIX B21 Wireless HDMI Adapter:

1. రిసీవర్ (RX) ని కనెక్ట్ చేయండి: Plug the HDMI connector of the Receiver (RX) into an available HDMI port on your display device (TV, monitor, or projector).
2. రిసీవర్‌కు శక్తినివ్వండి (RX): Connect the provided USB-C to A cable to the USB-C power supply port on the Receiver (RX). Plug the USB-A end into a USB power adapter (5V, 2A or higher recommended) or a powered USB port on your display device.
3. HDMI ఇన్‌పుట్‌ని ఎంచుకోండి: On your display device, use the remote control or menu buttons to select the corresponding HDMI input source where the Receiver (RX) is connected. The MINIX boot screen should appear.
4. ట్రాన్స్‌మిటర్ (TX)ని కనెక్ట్ చేయండి: Plug the USB-C connector of a Transmitter (TX) into the USB-C port of your source device (laptop, smartphone, tablet).
   • ముఖ్యమైన గమనిక: Your source device's USB-C port must support video signal transmission (DP-Alt Mode).
   • Some devices may require external power for the Transmitter (TX) to function correctly. If no signal appears after a few seconds, connect a power supply to the TX unit's USB-C port.
5. కనెక్షన్ ప్రారంభించండి: The Transmitter (TX) indicator light will flash and then become solid when a connection is established. The display from your source device should appear on your screen within approximately 10 seconds.

Image: A visual quick guide demonstrating the four steps for connecting the MINIX B21 Wireless HDMI Adapter: connecting the RX to the display, powering the RX, selecting the HDMI source, and connecting the TX to the source device.

ఆపరేటింగ్ సూచనలు

ప్లగ్ మరియు ప్లే ఫంక్షనాలిటీ

The MINIX B21 is designed for ease of use. Once connected, it operates as a plug-and-play device, requiring no driver installation or complex software setup. Your device's display will automatically mirror or extend to the connected screen.

Image: A laptop connected to a monitor via the MINIX B21, demonstrating both mirror mode (duplicate display) and extended mode (separate display) functionality.

Mirror and Extended Display Modes

Depending on your operating system settings, you can configure the external display to either mirror your primary screen or extend your desktop, providing more workspace. Adjust these settings directly from your source device's display preferences.

బహుళ-పరికర కనెక్టివిటీ

The MINIX B21 system includes two Transmitters (TX) and one Receiver (RX). This allows you to connect two source devices simultaneously and switch between them with ease. A single Receiver (RX) can be paired with up to four Transmitters (TX), enabling flexible management of multiple video sources. To pair additional Transmitters, refer to the re-pairing instructions in the manual.

Image: Two individuals in a meeting setting using MINIX B21 Transmitters connected to their laptops, wirelessly displaying content on a shared large screen, highlighting the multi-device capability.

One-Click Disconnect/Reconnect

For privacy or to temporarily stop transmission, simply press the function button on the Transmitter (TX) to disconnect. Press it again to reconnect and resume display.

అప్లికేషన్లు

The MINIX B21 is suitable for a variety of environments:

• హోమ్ ఎంటర్టైన్మెంట్: Stream movies, videos, or games from your devices to your TV.
• Office Presentations: Conduct professional presentations without the clutter of cables.
• Educational Settings: Share content from laptops or tablets with students on a larger display.
• గేమింగ్: Enjoy mobile or handheld console gaming on a big screen with minimal latency.

Image: Collage showing the versatility of the MINIX B21 in different scenarios, including a classroom, a home theater, a fitness session, and an outdoor movie night.

ట్రబుల్షూటింగ్

If you encounter issues with your MINIX B21, refer to the following common solutions:

1. డిస్ప్లేలో సిగ్నల్ లేదు:
   • Ensure the Receiver (RX) is properly connected to the HDMI port of your display and is receiving adequate power (5V, 2A or higher).
   • Verify that the correct HDMI input source is selected on your display.
   • Confirm that your source device's USB-C port supports video output (DP-Alt Mode). Not all USB-C ports support this function.
   • If your source device requires it, ensure the Transmitter (TX) is also connected to an external power source.
   • Try disconnecting and reconnecting both the TX and RX units.
2. Occasional Lag or Stuttering:
   • Ensure the distance between the Transmitter (TX) and Receiver (RX) is within the recommended 50-meter range and there are no significant obstructions.
   • Minimize interference from other wireless devices operating on the 5GHz band.
   • Check if your source device is running too many applications, which might affect performance.
3. Receiver (RX) Gets Warm:
   • It is normal for the Receiver (RX) unit to become warm during extended use. Ensure it has adequate ventilation and is not covered. If it becomes excessively hot or malfunctions, discontinue use and contact support.
4. Cannot Switch Between Transmitters:
   • Press the function button on the desired Transmitter (TX) to activate its signal. The RX unit should automatically switch to the active TX.
   • If you have new Transmitters or are using them from a different order, they may need to be re-paired with the Receiver (RX). Refer to the manual for specific re-pairing instructions.
5. Resolution Issues (Only 1080p Supported):
   • The MINIX B21 supports a maximum resolution of 1080p at 60Hz. It does not support 4K resolution. Ensure your source content and display settings are configured for 1080p for optimal performance.

స్పెసిఫికేషన్లు

భద్రతా సమాచారం

Please read and follow these safety guidelines to ensure proper operation and prevent damage to the device or injury:

• పరికరాన్ని నీరు, తేమ లేదా తీవ్రమైన ఉష్ణోగ్రతలకు గురిచేయవద్దు.
• పరికరాన్ని వదలడం లేదా బలమైన ప్రభావాలకు గురి చేయడం మానుకోండి.
• పరికరాన్ని విడదీయడానికి లేదా సవరించడానికి ప్రయత్నించవద్దు. ఇది వారంటీని రద్దు చేస్తుంది.
• Use only the provided or recommended power adapters and cables.
• పరికరాన్ని వేడి మూలాలు మరియు ప్రత్యక్ష సూర్యకాంతి నుండి దూరంగా ఉంచండి.
• Ensure adequate ventilation around the Receiver (RX) unit during operation to prevent overheating.

వారంటీ మరియు మద్దతు

MINIX products come with a standard manufacturer's warranty. For detailed warranty information, technical support, or service inquiries, please visit the official MINIX website or contact MINIX customer service directly. Please retain your proof of purchase for warranty claims.

తయారీదారు: MINIX Technology Limited
